Mobile TV cabinet with electric height adjustment "VSM electric"

Plug and play with connection panel, silver anodized column, 50cm stroke, incl. collision protection, TV lowboard
Item number: SCETASBNAPPK

Product description

Electrically height-adjustable TV cabinet with plug & play connection panel.

The TV cabinet The TV lowboard comes with 6 trumpet feet and 6 rubberized smooth-running castors, two of which are lockable. Use the trumpet feet if you want to position your display stand in front of a wall (no wall connection required) or freely in the room. Or opt for maximum flexibility and use the 6 rubberized smooth-running castors. The TV lowboard is supplied in brushed aluminum decor including two hinged doors in black. The TV cabinet has a connection panel with 2x HDMI, 1x USB 3.0 type A, 1x USB 2.0 type B (touch), 2x power sockets (220 V) and offers the ideal solution for use with interactive touchscreen monitors. Enjoy maximum convenience by opting for the fully assembled and completely wired SCETASBNAPP system.

The SCETASBNAPP comes with an electrically height-adjustable pylon column with a 50 cm stroke, including collision protection

The monitor mount accommodates touchscreen displays from 55 - 86 inches screen diagonal, with VESA 200 x 200 to 800 x 600 and up to a maximum of 136 kg.


Features

  • TV cabinet for use with displays up to 86 inches screen diagonal, incl. collision protection
  • Simple display mounting thanks to bracket with hanging rails with quick-release fastener
  • Display holder takes cable management into account
  • The motor system is securely installed inside the aluminum lifting column and provides a 50 cm stroke
  • A cable control unit is included in the scope of delivery
  • The sideboard comes with two adjustable shelves, 6 trumpet feet and 6 castors with a diameter of 75 mm as standard
  • Connection panel with 2x HDMI, 1x USB 3.0 type A, 1x USB 2.0 type B (touch), 2x power socket (220 V)
  • Assembled and ready wired with energy supply chain (Please note that the system is only available in a limited number of markets. Please contact our sales department for more information).
Product image Mobile TV cabinet with electric height adjustment
Product image Mobile TV cabinet with electric height adjustment Product image Mobile TV cabinet with electric height adjustment Product image Mobile TV cabinet with electric height adjustment Product image Mobile TV cabinet with electric height adjustment Product image Mobile TV cabinet with electric height adjustment Product image Mobile TV cabinet with electric height adjustment Product image Mobile TV cabinet with electric height adjustment

Icon display mounts
Display mount
Icon wallmounted system
Wall mounted
Icon platform stand
Free-standing
Icon mobile stand
Mobile
Icon electrical height adjustable
Motorized height adjustable
Icon single display
Single display
Icon 5 years warranty
5 years warranty
Icon maximum load
Max. load
299.8 lbs
Icon maximal VESA
Max. Vesa
800 x 600
Item numberSCETASBNAPPK
Vesa horizontal300 mm - 800 mm
Vesa vertical200 mm - 600 mm
Frame for all55" - 86"
Vertical travel50 cm
Center to floor distance 1357 mm - 1857 mm53.4" - 73.1"
Load capacity136 kg 299.8 lbs
Width 893 mm35.2"
Height 1685 mm - 2185 mm66.3" - 86"
Depth 580 mm22.8"
Weight 87,7 kg193.3 lbs
Warranty5 years limited warranty
Frame colorRAL 9005 deep black
Column colorSilver anodized
Base colorRAL 9006 white aluminum
Base colorRAL 9005 deep black
